Project Description

300W Coaxial Attenuator DC-8GHz 40dB

Specification Parameter
Model BC-AT300-40db-8G
Power 300W
Connector N-K(F)/N-K(F)
Frequency Range DC-8GHz
Attenuation 40dB ± 1.4dB
VSWR (MAX) 1.3:1
Impendance 50Ω
Temperature Range -55°C to +125°C
Dimension 78x80x200mm
Weight 2.1kg
DOWNLOAD

Download the manual you need!

This is the place where you could download our manual of the product.
DOWNLOAD
TEST REPORT

TEST REPORT

This is the test report of one attenuation. if you want to see me report of attenuation , please contact us now.
TEST REPORT

Application:

300W Coaxial Attenuator DC-8GHz 40dB is widely used in below fileds:

  • Mobile Communication Network Optimization and In-door distribution system.

  • Cluster communication, satellite communication, shortwave communication and hopping radio.

  • Radar, electronic navigation and electronic confrontation.

  • Aerospace equipment systems
